[GitHub] [skywalking] BFergerson opened a new pull request #4840: Increased Vert.x support

BFergerson opened a new pull request #4840:
URL: https://github.com/apache/skywalking/pull/4840

- Why submit this pull request?
- [x] Bug fix
- [ ] New feature provided
- [x] Improve performance

- Related issues

___
### Bug fix

Fixes https://github.com/apache/skywalking/issues/3338. @wentjiang had the right idea for the fix but the method chosen to enhance is not present ver. 3.5+. I've chosen another method that also works and is present in all versions.

___
### New feature or improvement

I added support for ver. 3.9.1 as well for more complex route handling. The tests I've been using were too simple so I made them more realisitic. The tests I'm using now look like:
- User sends request to `/web-case`
- `/web-case` sends a request to `/healthcheck` (ver. 3.5- = sync / ver. 3.6+ = async)
- Once response is recieved another request is sent to `/withBodyHandler` (ver. 3.5- = sync / ver. 3.6+ = async)
- Before `/withBodyHandler` is called this is processed by Vert.x's internal `BodyHandler`
- `BodyHandler` passes request off to `/withBodyHandler`
- Once the response is received the original request to `/web-case` is responded to

This results in the segment trace stack:
```
ENTER: /case/web-case
ASYNC SPAN STARTED [1]
LOCAL: VertxWebController$$Lambda$.handle(RoutingContext)
EXIT: /case/healthCheck
ASYNC SPAN STARTED [2]
CLOSE EXIT
CLOSE LOCAL
CLOSE ENTER

ENTER: /case/healthCheck
ASYNC SPAN STARTED [3]
LOCAL: VertxWebController$$Lambda$.handle(RoutingContext)
ASYNC SPAN FINISHED [3]
CLOSE LOCAL
CLOSE ENTER

ASYNC SPAN FINISHED [2]
LOCAL: #/case/healthCheck
EXIT: /case/web-case/withBodyHandler
ASYNC SPAN STARTED [4]
CLOSE EXIT
CLOSE LOCAL

ENTER: /case/web-case/withBodyHandler
ASYNC SPAN STARTED [5]
LOCAL: BodyHandlerImpl.handle(RoutingContext)
EXIT LOCAL
CLOSE ENTER

LOCAL: VertxWebController$$Lambda$.handle(RoutingContext)
ASYNC SPAN FINISHED [5]
CLOSE LOCAL

ASYNC SPAN FINISHED [4]
LOCAL: #/vertx-web-3_54minus-scenario/case/web-case/withBodyHandler
ASYNC SPAN FINISHED [1]
CLOSE LOCAL
```

If you look at the above the `ENTER: /case/web-case/withBodyHandler` is called on a separate context than `LOCAL: VertxWebController$$Lambda$.handle(RoutingContext)`. This is because of the added `BodyHandlerImpl.handle(RoutingContext)`. This would occur with any additional handlers before the user-code handler. With the added solution you can add additional handlers (e.g. `CorsHandler`) and it'll still result in the spans being created correctly:
![trace-list](https://user-images.githubusercontent.com/3278877/83239063-591ef480-a1a8-11ea-9afb-65a37c5d7c0e.png)

Apologies for the constant changes. I believe this PR to offer the most thorough support and I wanted to make sure to get better Vert.x support in SkyWalking 8.0.0. When I saw the previous PR couldn't support 3.9.1, I rushed it through because I saw there were bigger changes that I needed to make and I wasn't sure how quickly I could make them.

----------------------------------------------------------------
